be quiet! Straight Power 11 850W raises the bar for systems that demand virtually inaudible operation without power quality compromises. |
- Virtually inaudible SilentWings 3 135mm fan
- Funnel-shaped fan opening of the PSU case for high airflow intake
- Wire-free inside the PSU on the DC side for enhanced cooling and longevity
- Full cable management for maximum build flexibility
- 80PLUS Gold efficiency (up to 93%)
- Powerful multi-GPU support with four PCI-Express connectors
- Japanese 105°C-rated capacitors ensure stability and reliability
- ErP and Energy Star 6.1 ready
|
Savybės |
80 PLUS Certification |
80 PLUS Gold |
Colour |
Black |
Cooling System |
135 mm fan |
Device Type |
Power supply - active Power Factor Correction (PFC) - internal |
Dimensions (WxDxH) |
15 cm x 17 cm x 8.6 cm |
Environmental Standards |
ENERGY STAR |
Included Accessories |
Screws, cable ties |
Input Voltage |
AC 100-240 V |
Manufacturer Warranty |
5-year warranty |
Output connectors |
1 x power 24 pin ATX with detachable 4 pin section 1 x power 8 pin +12V with detachable 4 pin section 4 x 8 pin PCI Express power with detachable 2 pin section 4 x 4 PIN internal power 11 x 15 pin Serial ATA power 1 x 4 PIN mini-power connector |
Output Current |
+3.3V - 25 A +5V - 25 A +12V1 - 21 A +12V2 - 21 A +12V3 - 26 A +12V4 - 26 A -12V - 0.5 A +5VSB - 3 A |
Output Voltage |
+3.3, +5, 12 V |
Power Capacity |
850 Watt |
Product Description |
be quiet! Straight Power 11 850W - power supply - 850 Watt |
Specification Compliance |
ATX12V 2.4/ EPS12V 2.92 |
Weight |
1.8 kg |
